ENGLISH

Tiling Displays

How to Mount the Set

Example of 2x2 Tiling

Using the screws for attaching the VESA wall mount, mount the set to the wall mount plate or the wall.

Screws for attaching the VESA wall

mount (M6)

(Unit: mm (inches))

600 (23.6)

400 (15.7)
