LG 72WS70MS - Page 65

65
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
01. Power (Command: k a)
To control Power On/Off of the set.
Transmission
[k][a][ ][Set ID][ ][Data][Cr]
Data
00 : Power Off
01 : Power On
Acknowledgement
[a][ ][Set ID][ ][OK][Data][x]
To show the status of Power On/Off.
Transmission
[k][a][ ][Set ID][ ][FF][Cr]
Acknowledgement
[a][ ][Set ID][ ][OK][Data][x]
Data
00 : Power Off
01 : Power On
03. Screen Mute (Command: k d)
To select screen mute on / off.
Transmission
[k][d][ ][Set ID][ ][Data][Cr]
Data
00: Screen mute off (Picture on)
01 : Screen mute on (Picture off)
Acknowledgement
[d][ ][Set ID][ ][OK][Data][x]
02. Aspect Ratio (Command: k c)
To adjust the screen format.
You can also adjust the screen format using the ARC
(Aspect Ratio Control) button on remote control or in
the Screen menu.
Transmission
[k][c][ ][Set ID][ ][Data][Cr]
Data
01 : Normal Screen (4 : 3)
02 : Wide Scran (16 : 9)
04 : Zoom
(AV,Component,HDMI/Display Port DTV)
09 : Just Scan
(Component,HDMI/Display Port DTV)
* When the RGB, DVI-D, HDMI/ Display Port PC
mode (1:1)
10 to 1F : Cinema Zoom 1 to 16
( AV, Component, HDMI/Display Port DTV)
Acknowledgement
[c][ ][Set ID][ ][OK][Data][x]
04. Volume Mute (Command: k e)
To control On/Off of the Volume Mute.
Transmission
[k][e][ ][Set ID][ ][Data][Cr]
Data
00 : Volume Mute On (Volume Off)
01 : Volume Mute Off (Volume On)
Acknowledgement
[e][ ][Set ID][ ][OK][Data][x]
Data
00 : Volume Mute On (Volume Off)
01 : Volume Mute Off (Volume On)
05. Volume Control (Command: k f)
To adjust Volume.
Transmission
[k][f][ ][Set ID][ ][Data][Cr]
Data
Min : 00H to Max : 64H
(Hexadecimal code)
Acknowledgement
[f][ ][Set ID][ ][OK][Data][x]
Data
Min : 00H to Max : 64H
* Real data mapping
Hexadecimal Num.
(Setting Value)
Decimal Num.
(Real Value)
0 0
A 10
F 15
10 16
20
32
64 100
