MAKING CONNECTIONS
HDMI - See p.49
Component - See p.49
AV(CVBS) - See p.50
RGB - See p.12
DVI-D - See p.12
HDMI - See p.13
Display Port - See p.13
LAN - See p.51
HDMI - See p.49
Component - See p.49
AV(CVBS) - See p.50
HDMI - See p.49
Component - See p.49
AV(CVBS) - See p.50
AV(CVBS) - See p.50
Component - See p.49
HDMI - See p.49
Component - See p.49
AV(CVBS) - See p.50
MAKING CONNECTIONS
Connect various external devices to the ports on the Monitor’s back panel.
1
Find an external device you want to connect to your Monitor shown on the following illustration.
2
Check the connection type of the external device.
3
Go to the appropriate illustration and check the connection details.
y
If you connect a gaming device to the Monitor, use the cable supplied with the gaming device.
HD Receiver DVD VCR
USB
PC
Camcorder/Camera
Gaming device
Speaker
Memory storage
– See p.21
NOTE
