LG 79UC970T - Preparing Built-In Camera; Name of Parts for the Built-In Camera; Checking the Cameras Shooting Range; Note

ENG
ENGLISH
22
ASSEMBLING AND PREPARING
Preparing Built-in Camera
1 Pull up the built-in camera at the back of
the TV.
Angle Adjustment Lever
Slide
• Remove the protective film before using the
built-in camera.
NOTE
2 You can adjust the angle of the camera with
the angle adjustment lever on the back of the
built-in camera (within 5 degrees vertically).
[Side View]
7˚
7˚
5˚
5˚
Lever Lens
3 Pull down the built-in camera when you are
not using it.
Name of Parts for the Built-In
Camera
Camera Lens
Protective film
Microphone
Checking the Camera’s Shooting
Range
1 Press the (Home) button to access the
Home menu.
2 Select CAMERA and then
press the Wheel (OK) button.
• The optimal distance from the camera to
use the motion recognition function is be-
tween 1.5 m and 4.5 m.
NOTE
