LG 901B User Manual

- 23 -
DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CN1040K949 0.1M 50V Z F TA52
C301 0CE477CF618 470UF SHL 16V M FL TP5
C302 0CE107CF638 100UF SHL,SD 16V M FM5 TP 5
C303 181-288B MKT 100V 104JTR PHS26104
C304 181-288N MKT 100V 103JTR PHS86103
C305 181-288N MKT 100V 103JTR PHS86103
C306 0CN1040K949 0.1M 50V Z F TA52
C307 0CN1040K949 0.1M 50V Z F TA52
C308 0CN1040K949 0.1M 50V Z F TA52
C309 181-288B MKT 100V 104JTR PHS26104
C310 0CK1040K945 0.1UF 50V Z F TR
C312 181-288B MKT 100V 104JTR PHS26104
C313 181-288B MKT 100V 104JTR PHS26104
C314 181-288B MKT 100V 104JTR PHS26104
C315 181-288B MKT 100V 104JTR PHS26104
C316 0CK10302940 0.01M 2KV Z F S
C317 0CE106CN638 10UF SHL,SD 100V M FM5 TP 5
C318 181-288B MKT 100V 104JTR PHS26104
C319 0CK10302940 0.01M 2KV Z F S
C320 0CE107CN630 100U SHL 100V M FM5
C321 0CE107EF638 100UF KMG 16V M FM5 TP 5
C322 0CN1040K949 0.1M 50V Z F TA52
C323 0CE476EN618 47UF KMG 100V M FL TP 5
C324 181-288B MKT 100V 104JTR PHS26104
C325 0CC3300K415 33P 50V J NP0 TP
C326 181-288B MKT 100V 104JTR PHS26104
C327 181-288B MKT 100V 104JTR PHS26104
C329 181-288B MKT 100V 104JTR PHS26104
C330 181-288B MKT 100V 104JTR PHS26104
C332 181-288E MKT 100V 474JTR PHS 26474
C333 181-288E MKT 100V 474JTR PHS 26474
C334 181-288E MKT 100V 474JTR PHS 26474
C336 0CK1010W515 100P 500V K B TS
C337 181-288B MKT 100V 104JTR PHS26104
C340 0CE227CF638 220UF SHL,SD 16V M FM5 TP 5
C341 181-288B MKT 100V 104JTR PHS26104
C342 0CC2200W415 22PF 500V J NP0 TR
C343 0CK1010K515 100PF 50V K B TR
C345 0CK22202510 2200P 2KV K B S
C346 0CC47001505 47PF 1KV K SL TR
C347 0CC47001505 47PF 1KV K SL TR
C348 0CK1040K945 0.1UF 50V Z F TR
C349 181-288E MKT 100V 474JTR PHS 26474
C350 0CK2210K515 220P 50V K B TS
C355 0CK1040K945 0.1UF 50V Z F TR
C356 0CN6810K519 680P 50V K B TA52
C401 0CC5600K415 56P 50V J NP0 TP
C402 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C403 0CK2710K515 270P 50V K B TS
C404 0CK2710K515 270P 50V K B TS
C405 0CK2710K515 270P 50V K B TS
C406 0CC0400K115 4P 50V D NP0 TS
C407 0CC0400K115 4P 50V D NP0 TS
DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C408 0CN1040K949 0.1M 50V Z F TA52
C410 0CK1040K945 0.1UF 50V Z F TR
C417 0CK1040K945 0.1UF 50V Z F TR
C418 0CN1040K949 0.1M 50V Z F TA52
C452 0CE106CF638 10UF SHL,SD 16V M FM5 TP 5
C453 0CE106CF638 10UF SHL,SD 16V M FM5 TP 5
C454 0CK1040K945 0.1UF 50V Z F TR
C455 0CK1040K945 0.1UF 50V Z F TR
C459 0CK1010K515 100PF 50V K B TR
C601 0CZZTFT001R ECQB1H223JM3 223J 50V TP5.0 MA
C602 181-288B MKT 100V 104JTR PHS26104
C603 0CK1020W515 1000P 500V K B TS
C604 0CE477CH618 470UF SHL 25V M FL TP5
C605 0CE476CN618 47UF SHL 100V M FL TP5
C701 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C702 0CE227EN630 220UF KMG 100V M FM5 BULK
C704 0CBZTBU003J 392J 20.0*12.5*7.5*10.0 800V J
C705 0CE336CN638 33UF SHL,SD 100V M FM5 TP 5
C707 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C708 0CE476CQ618 47U SHL 200V M FL TP5
C709 181-477A 102J 19.5*12.0*7.0*7.5 250V J
C711 0CQ4721N419 0.0047U 100V J POLY NI TP5
C712 0CK2220K515 2200P 50V K B TS
C713 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C730 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C731 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
C732 0CK1040K945 0.1UF 50V Z F TR
C735 0CC1000W105 10PF 500V D SL TR
C736 0CC1000W105 10PF 500V D SL TR
C737 0CQ2221N419 2200PF 100V J PE NI TP
C738 0CE685CN638 6.8UF SHL,SD 100V 20% TP 5 FM5
C740 0CK10302945 0.01UF 2KV Z F TR
C741 0CQ2231N419 0.022UF 100V J PE NI TP
C742 0CK4710K515 470PF 50V K B TR
C743 0CE106CN638 10UF SHL,SD 100V M FM5 TP 5
C771 0CK6810K515 680P 50V K B TS
C772 0CK4710W515 470P 500V K B TS
C801 0CQ6821N419 6800PF 100V J PE NI TP
C802 181-288B MKT 100V 104JTR PHS26104
C803 0CE106CK638 10UF SHL,SD 50V M FM5 TP 5
C804 181-288D MKT 100V 473JTR PHS26473
C805 181-475E 222J 11.5*10.0*6.0*5.0 100V J
C806 0CE227CH638 220UF SHL,SD 25V M FM5 TP 5
C807 181-288B MKT 100V 104JTR PHS26104
C808 0CC1000K115 10P 50V D NP0 TS
C809 0CK1020K515 1000PF 50V K B TR
C810 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
C811 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C812 0CE107CH638 100UF SHL,SD 25V M FM5 TP 5
C813 0CE106CF638 10UF SHL,SD 16V M FM5 TP 5
C814 0CK5610K515 560P 50V K B TS
C815 0CE227CF638 220UF SHL,SD 16V M FM5 TP 5
C817 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C818 181-288J MKT 100V 563JTR PHS26563
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
CAPACITORS
