DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C819 181-477U 333J 19.5*13.0*7.5*7.5 250V J
C821 0CK1040K945 0.1UF 50V Z F TR
C823 0CK1010K515 100PF 50V K B TR
C832 0CK10102515 100PF D 2KV 10% B(Y5P) TR
C841 0CE107CR650 100UF SHL 250V M FM7.5 BULK
C842 0CBZTTA002A 2000PF D 2.5KV J M/PP NI TP7.5
C843 0CQ3321N419 3300P 100V J POLY NI TP
C844 0CBZTTA002A 2000PF D 2.5KV J M/PP NI TP7.5
C845 181-288B MKT 100V 104JTR PHS26104
C846 0CE477CF638 470UF SHL TYPE 16V M FM5 TP 5
C847 0CQ2221N419 2200PF 100V J PE NI TP
C848 0CK47101515 470P 1KV K B TS
C849 0CK6810W515 680P 500V K B TS
C850 0CK1040K945 0.1UF 50V Z F TR
C851 0CK1040K945 0.1UF 50V Z F TR
C852 0CN1040K949 0.1M 50V Z F TA52
C854 181-482J 394J 18.0*19.0*12.0*7.5 250V J
C855 181-477Y 683JF 20.0*16.5*9.5*7.5 250V J
C856 181-305Y MPP 250 204J S=10.0
C857 181-305N 105J 26.0*22.5*14.0*15.0 250V
C858 181-303A 104J 20.5*18.5*10.5*10.0 250V
C859 181-303C 154J 30.0*17.5*10.5*20.0 250V
C860 0CN1040K949 0.1M 50V Z F TA52
C861 0CN1040K949 0.1M 50V Z F TA52
C863 0CN1040K949 0.1M 50V Z F TA52
C864 0CN1040K949 0.1M 50V Z F TA52
C865 0CE105CK638 1UF SHL,SD 50V 20% FM5 TP 5
C891 0CZZTFT001J ECQB1H562JM3 562J 50V TP5.0 MA
C892 0CZZTFT001M ECQB1H103JM3 103J 50V TP5.0 MA
C893 181-288B MKT 100V 104JTR PHS26104
C894 0CZZTFT001L ECQB1H822JM3 822J 50V TP5.0 MA
C895 181-288B MKT 100V 104JTR PHS26104
C896 181-288Q MKT 100V 154JTR PHS26154
C902 0CKZTTA003C SC E 472M 14.0FF7 250V TP7.5 S
C903 0CK10101515 100PF 1KV K B TR
C904 181-304V 393J 19.5*15.5*9.5*10.0 400V J
C905 181-296F 330UF SMH(30*40) 400V M VNSN
C906 0CE475CN638 4.7UF SHL,SD 100V M FM5 TP 5
C907 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C908 0CK1040K945 0.1UF 50V Z F TR
C909 181-288T MKT 100V 223KTR PHS85223
C910 0CZZTFT001P ECQB1H153JM3 153J 50V TP5.0 MA
C912 0CE475CN638 4.7UF SHL,SD 100V M FM5 TP 5
C915 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C916 0CKZTTA003C SC E 472M 14.0FF7 250V TP7.5 S
C917 0CKZTTA003C SC E 472M 14.0FF7 250V TP7.5 S
C920 0CK22101515 220P 1KV K B TP5
C921 0CE227CR650 220UF SHL 250V M FM7.5 BULK
C922 0CE227EN630 220UF KMG 100V M FM5 BULK
C923 0CK10101515 100PF 1KV K B TR
C925 0CE228CH618 2200U SHL 25V M FL TP5
C926 0CE108EF618 1000UF KMG 16V M FL TP 5
C927 0CE108CH630 1000UF SHL 25V M FM5 BULK
C928 0CE108EF618 1000UF KMG 16V M FL TP 5
C929 0CK1020K515 1000PF 50V K B TR
C930 181-288H MKT 100V 333JTR PHS 86333
C953 0CE477CF638 470UF SHL TYPE 16V M FM5 TP 5
C958 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
C970 0CE476CH638 47UF SHL,SD 25V M FM5 TP 5
DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D201 0DL305029BA LTL-305DJ-0C2 TP LITEON GREEN/
D301 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D302 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D303 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D304 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D305 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D306 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D307 0DS124409AA 1SS244 TP ROHM KOREA
D308 0DS124409AA 1SS244 TP ROHM KOREA
D309 0DS124409AA 1SS244 TP ROHM KOREA
D310 0DS124409AA 1SS244 TP ROHM KOREA
D311 0DS124409AA 1SS244 TP ROHM KOREA
D312 0DS124409AA 1SS244 TP ROHM KOREA
D313 0DS124409AA 1SS244 TP ROHM KOREA
D314 0DS124409AA 1SS244 TP ROHM KOREA
D315 0DS124409AA 1SS244 TP ROHM KOREA
D318 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D319 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D401 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D402 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D404 0RD4701Q609 4.70K 1/4W(3 5% TA52
D405 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D451 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D452 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D453 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D454 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D701 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D702 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D703 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D704 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D706 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D707 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D708 0DRFJ00011A YG339D6F208 FUJI ST TO220 -400
D709 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D710 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D731 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D732 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D733 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D734 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D735 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D736 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D737 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D738 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D739 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D771 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D772 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D773 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D801 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D802 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D803 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D804 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D805 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D808 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D811 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D812 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D831 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D833 0DR140059DA 1N4005TB52 TP LITEON DO41 600V
D834 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D837 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D838 0DR200000EA FMQ-G2FMS BK SANKEN NON 1500V
D839 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
- 24 -
DIODEs
