LG 901B User Manual

DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D840 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D861 0DD140009AA EK14 V(1) TP SANKEN E/EO-TMD 4
D901 0DD360000DB D3SB60 SHINDENKEN
D902 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D903 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
D904 0DD100009DA RGP10J TP G.I DO204AL 600V 1A
D905 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D906 971-0054 TIN 50MM TAPING
D907 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D908 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D910 0DR153979AA 1N5397GP TP G.I DO201AD 600V 1
D911 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D912 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D920 0DRSD00079A D2L20U SHINDENGEN TP DO-204AC
D921 0DR320400AA S3L20U-4004P15 BK SHINDENGEN N
D922 0DR320400AA S3L20U-4004P15 BK SHINDENGEN N
D923 0DR360000AB D3L60 BK SHINDENGEN ITO220 6
D924 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D925 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D926 0DR260400AA S2L60-4004P15 BK SHINDENGEN NO
D927 0DS141489AB 1N4148 TP GRANDE DO-34 500MW 1
D928 971-0054 TIN 50MM TAPING
D929 0DD100009DE RGP10G TP G.I DO204AL 400V 1A
ZD201 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD202 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD203 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD303 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD306 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD402 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD403 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD404 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD405 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD407 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD408 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD409 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD410 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD601 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD703 0DZ510009BE GDZ5.1B TP GRANDE DO34 500MW 5
ZD711 0DZ910009AH MTZJ9.1B TP ROHM-K DO34 500MW
ZD712 0DZ560009AG GDZJ5.6B TP GRANDE DO-34 500MW
ZD802 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD804 0DZ180009BD GDZJ18B TP GRANDE DO34 0.5W 18
ZD901 0DZ240009BJ GDZJ24B TP GRANDE DO34 500MW 2
IC301 0IPRPNV009A NT68275-00027 NOVATEK 16P, DIP
IC302 0IPRPNS008A LM1267NA NATIONAL SEMICONDUCTO
IC303 0IPRPNS007A LM2463TA NATIONAL SEMICONDUCTO
IC304 0IPRPNS005A LM2480NA NATIONAL SEMICONDUCTO
IC401 0IZZTSZ179C WT62PI WELTREND 42 ST MTP FB99
IC402 0ISG240860A M24C08-BN6 8DIP BK 8K SERIAL I
IC601 0IPH486600C TDA4866J 9P ST VERTICAL OUTPUT
IC801 0IPRPPH005A TDA4841PS PHILIPS 32P,SDIP ST
IC802 0IMI625010A M62501P 16P4 BK INTERFACE PWM
IC901 0ISS384200A KA3842B (PWM)
IC904 0ISS781200F KA7812
IC905 0ISS780500F KA7805
L304 0LA1000K119 100UH K 2.3*3.4 TP
DATE: 2002. 9. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L305 0LA0390K119 0.39UH K 2.3*3.4 TP
L306 0LA0390K119 0.39UH K 2.3*3.4 TP
L307 0LA0390K119 0.39UH K 2.3*3.4 TP
L308 971-0054 TIN 50MM TAPING
L309 971-0054 TIN 50MM TAPING
L310 971-0054 TIN 50MM TAPING
L701 6140TBZ009C NO CORE 10UH 0.12*15MM 50.5T F
L801 6140TYZ011B - GET DR14*15 EB990G H-LIN
L806 150-985N DR10*10 4.7UH 0.16MM 322.5T
L901 6140TBZ031B EE36SI PFC 49MH 0.5MM 228 +/-
FB201 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB301 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB302 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB303 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB304 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB305 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB306 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB307 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB308 125-022J FERRITE KQ-1 JS 3.5*5.0MM AXIA
FB309 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB310 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB312 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB313 125-155K BFS3550A0FG SAMWHA 3.5*5.0MM A
FB314 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB315 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB316 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB317 125-155A BFD3510R2FG SAMWHA 3.5*10MM RA
FB401 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB402 125-155N BFD3565R2FG SAMWHA 3.5*6.5MM R
FB403 125-155L BFS3580A0FG SAMWHA 3.5*8.0MM A
FB841 125-155P BFS2550R2FG SAMWHA 2.5*5.0MM R
FB902 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB903 125-155C BFD3514R2FG SAMWHA 3.5*14MM RA
FB904 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB905 125-155C BFD3514R2FG SAMWHA 3.5*14MM RA
FB906 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
FB907 125-155J BFS2550A0FG SAMWHA 2.5*5.0MM A
FB908 125-155H BFS3510A0FG SAMWHA 3.5*10MM AX
Q301 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q302 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q451 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q452 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q453 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q454 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q455 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q456 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q701 0TR320509AB KTC3205-Y(KTC2236A) TP KEC TO9
Q704 0TFFN10003B INFINEON SPA07N60C3 ST TO220F
Q705 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO92
Q706 0TR127009AA KTA1270-Y(KTA562TM) TP KEC TO9
Q707 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q708 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO92
Q721 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q722 0TR390600CA 2N3906 TP SAMSUNG TO92 NPN
Q723 0TR390409CA 2N3904 TP SAMSUNG TO92 NPN
Q724 0TR463300AB 2SC4633(LS-CB11) BK SANYO LS-
Q771 0TR920009AB KSP92 TP SAMSUNG TO92 HIGH VOL
Q801 0TR558900BA 2SC5589(LG,W/M) BK TOSHIBA TO3
Q802 0TR471009AA KSD471AC-Y TP SAMSUNG TO92 NP
- 25 -
ICs
COILs & COREs
TRANSISTOR
