LG A09AW1 User Manual

ENGLISH
Owner's Manual 11
To lower the temperature
To raise the temperature
4
2
1
3
Cooling
Auto
Changeover
Healthy
Dehumidification
Heating
(Heat pump model only)
Air Circulation
CHAOS Air Fan speed is on low. Fan speed is on medium. Fan speed is on high.
Operating Instructions
Press the ON/OFF BUTTON to turn
the unit on.
The unit will respond with a beep.
Open the door of the remote controller and press the
operation mode button. Each time the button is pressed, the
operation mode is shifted in the direction of the arrow.
Auto Operation (Cooling Only Model)
Auto Changeover (Heat Pump Model)
For cooling or heating operation set the desired indoor
temperature by pressing the ROOM TEMPERATURE
SETTING BUTTONS.
For cooling the temperature can be set within 18°C~30°C and
for heating the temperature range is 16°C~30°C.
Set the fan speed with the remote controller. You can select the fan speed in four steps-low,
medium, high and CHAOS by pressing the INDOOR FAN SPEED SELECTOR BUTTON.
Each time the button is pressed, the fan speed mode is shifted.
1
2
3
4
Natural wind by the CHAOS logic
❏
For fresher feeling, press the INDOOR FAN SPEED SELECTOR BUTTON selector and set to CHAOS mode.
In this mode, the wind blows like a natural breeze by automatically changing fan speed according to the CHAOS logic.
Operation Mode

LG A09AW1 Specifications

General

Type	Split system
Thermostat range	16 - 30 °C
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	9210 BTU/h
Heating capacity (max)	11940 BTU/h
Cooling capacity in watts (max)	2700 W
Heating capacity in watts (max)	3500 W
Cooling energy efficiency (EER, W/W)	3.25
Indoor unit type	Wall-mountable
Power requirements	AC 230V, 3.8/4.4A
Power consumption (typical)	830 W

Weight and Dimensions

Weight	15000 g
Dimensions (WxDxH)	600 x 146 x 600 mm
