Installation space
Installation space
Individual Installation
Collective / Continuous Installation
Required the minimum space as shown below for installation and
check. If the space is not fit on this drawing, consult with LG.
Space required for collective installation and continuous installation as shown below considering passage for air
and people.
: Service area
S
* In case of the water pipe passing side product, please make sufficient service place to avoid occurring
between water pipe and product side.
: Service area
S
H-Beam Support
(unit : mm)
1120 100100
<Front View>
20 100
350
772
Water pipe
installation
space
600 547 20
Product
(Outdoor unit)
<Top View>
Service area
(Front)
Product
(Outdoor unit)
Product
(Outdoor unit)
(Unit : mm)
<Top view>
20
350
350
772
100
772 100
600 547
20
Product
(Outdoor unit)
Product
(Outdoor unit)
<Top view>
20
350
350
772
100
772
Product
(Outdoor unit)
(Unit : mm)
350
100
772 100
600 547
20
ENGLISH
Installation Manual 11
