Outside units Information
8 Outside Unit
Outside units Information
Power Supply: Outside Unit (3Ø, 380 ~ 415V, 50Hz)
■ Heat pump
Unit
System(HP)
Model
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg
Dimension(W x H x D) mm
inch
Refrigerant Liquid(mm/inch)
Connecting Pipes Gas(mm/inch)
Water Inlet
Connecting Pipes Outlet
Drain Outlet
Range of Operation Cooling(°C)
Water Temp. Heating(°C)
1 Unit 2 Unit
08 10 20 30
ARWB80LA2 ARWB100LA2 ARWB200LA2 ARWB300LA2
ARWB80LA2 ARWB100LA2 ARWB200LA2 ARWB200LA2
ARWB100LA2
7.3 7.3 8.8 7.3+8.8
1.5 1.5 3 4.5
13 16 32 49
170 170 238 170 + 238
772 x 1,120 x 547 772 x 1,120 x 547 772 x 1,120 x 547 (772 x 1,120 x 547) x 2
30.4 x 44.1 x 21.5 30.4 x 44.1 x 21.5 30.4 x 44.1 x 21.5 (30.4 x 44.1 x 21.5) x 2
9.52(3/8) 9.52(3/8) 12.7(1/2) 19.05(3/4)
22.2(7/8) 22.2(7/8) 28.58(1 1/8) 34.9(1 3/8)
PT32A (internal thread) PT32A (internal thread) PT40A (internal thread) PT32A + PT40A (internal thread)
PT32A (internal thread) PT32A (internal thread) PT40A (internal thread) PT32A + PT40A (internal thread)
20mm (internal thread) 20mm (internal thread) 20mm (internal thread) 20mm (internal thread)
10 ~ 45 10 ~ 45 10 ~ 45 10 ~ 45
10 ~ 45 10 ~ 45 10 ~ 45 10 ~ 45
Unit
System(HP)
Model
Product Charge kg
CF(Correction Factor) kg
Max. Connectable No. of Indoor Units
Net Weight kg
Dimension(W x H x D) mm
inch
Refrigerant Liquid(mm/inch)
Connecting Pipes Gas(mm/inch)
Water Inlet
Connecting Pipes Outlet
Drain Outlet
Range of Operation Cooling(°C)
Water Temp. Heating(°C)
2 Unit 3 Unit
40 50 60
ARWB400LA2 ARWB500LA2 ARWB600LA2
ARWB200LA2 ARWB200LA2 ARWB200LA2
ARWB200LA2 ARWB200LA2 ARWB200LA2
ARWB100LA2 ARWB200LA2
8.8+8.8 7.3+8.8+8.8 8.8+8.8+8.8
6 7.5 9
64 64 64
(238) x 2 170 + (238) x 2 (238) x 3
(772 x 1,120 x 547) x 2 (772 x 1,120 x 547) x 3 (772 x 1,120 x 547) x 3
(30.4 x 44.1 x 21.5) x 2 (30.4 x 44.1 x 21.5) x 3 (30.4 x 44.1 x 21.5) x 3
19.05(3/4) 19.05(3/4) 19.05(3/4)
41.3(1 5/8) 41.3(1 5/8) 41.3(1 5/8)
PT40A + PT40A (internal thread) PT32A + PT40A + PT40A (internal thread) PT40A + PT40A + PT40A (internal thread)
PT40A + PT40A (internal thread) PT32A + PT40A + PT40A (internal thread) PT40A + PT40A + PT40A (internal thread)
20mm (internal thread) 20mm (internal thread) 20mm (internal thread)
10 ~ 45 10 ~ 45 10 ~ 45
10 ~ 45 10 ~ 45 10 ~ 45
• Ratio of the running Indoor Units to the Outside: Within 10 ~ 100%
• A combination operation over 100% cause to reduce each indoor unit capacity.
■ Combination Ration(50~200%)
Notes:
* We can guarantee the operation only within 130% Combination.
If you want to connect more than 130% combination, please contact us and discuss the require-
ment like below.
1) If the operation of indoor unit is more than 130%, low airflow operation is recommended in all
the indoor units.
2) If the operation of indoor unit is more than 130%, additional refrigerant is needed according to
the Äheadquarter guidance.
3)Over 130%, capacity is same as capacity of 130%, Same remark is valid for power input.
Outside Number Connection Capacity
Single outside units 200%
Double outside units 160%
Triple outside units 130%
