LG AS-C076QLA0 - Cooling Performance Data

60 2005 Product Data
8. Performance Data Cooling
LS-J0762FL(ML)
■ Symbol
AFR: Air flow rate...........................................................[m3/min]
DB: Dry bulb temperature......................................................[˚C]
WB: Wet bulb temperature ....................................................[˚C]
TC: Total capacity.................................................................[kW]
SHC: Sensible capacity........................................................[kW]
PI: Power Input.....................................................................[kW]
(Comp.+ indoor fan motor+outdoor fan motor)
■ Notes :
1. All capacites are net, evaporator fan motor heat is deducted.
2. Indicates nominal capacity.
3. Direct interpolation is permissible. Do not extrapolate
4. Capacities are based on the following conditions:
- Interconnecting Piping Length 7.5m
- Level Difference of Zero.
˚CWB ˚CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 20 1.7 1.3 0.5 1.6 1.3 0.5 1.6 1.2 0.6 1.5 1.2 0.7 1.4 1.2 0.7 1.4 1.2 0.7
16 22 1.9 1.5 0.5 1.9 1.4 0.6 1.8 1.4 0.6 1.8 1.4 0.7 1.7 1.3 0.7 1.7 1.3 0.7
18 25 2.2 1.6 0.5 2.1 1.6 0.6 2.0 1.5 0.7 2.0 1.5 0.7 1.9 1.5 0.7 1.8 1.4 0.8
19 27 2.3 1.6 0.5 2.2 1.6 0.6 2.1 1.6 0.7 2.1 1.5 0.7 2.0 1.5 0.7 1.9 1.5 0.8
22 30 2.5 1.7 0.5 2.4 1.7 0.6 2.3 1.7 0.7 2.3 1.6 0.7 2.2 1.6 0.8 2.1 1.6 0.8
24 32 2.6 1.8 0.5 2.5 1.7 0.6 2.4 1.7 0.7 2.3 1.6 0.7 2.2 1.6 0.8 2.2 1.6 0.8
Indoor Air
Temperature
Outdoor Air Temperature : ˚ CDB
20 25 32 35 40 43
LS-J0762RL(PL)
˚CWB ˚CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 20 1.7 1.3 0.5 1.6 1.3 0.6 1.6 1.2 0.7 1.5 1.2 0.7 1.4 1.2 0.8 1.4 1.2 0.8
16 22 1.9 1.4 0.5 1.9 1.4 0.6 1.8 1.4 0.7 1.8 1.4 0.7 1.7 1.3 0.8 1.7 1.3 0.8
18 25 2.2 1.6 0.5 2.1 1.6 0.6 2.0 1.5 0.7 2.0 1.5 0.7 1.9 1.4 0.8 1.8 1.4 0.8
19 27 2.3 1.6 0.5 2.2 1.6 0.6 2.1 1.6 0.7 2.1 1.5 0.8 2.0 1.5 0.8 1.9 1.5 0.8
22 30 2.5 1.7 0.5 2.4 1.7 0.6 2.3 1.6 0.7 2.3 1.6 0.8 2.2 1.6 0.8 2.1 1.5 0.8
24 32 2.6 1.8 0.5 2.5 1.7 0.6 2.4 1.7 0.7 2.3 1.6 0.8 2.2 1.6 0.8 2.2 1.5 0.8
Indoor Air
Temperature
Outdoor Air Temperature : ˚ CDB
20 25 32 35 40 43
LS-J0962FL(ML)
˚CWB ˚CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 20 2.1 1.6 0.6 2.1 1.6 0.7 2.0 1.5 0.8 1.9 1.5 0.9 1.9 1.5 0.9 1.8 1.4 1.0
16 22 2.5 1.8 0.6 2.4 1.8 0.7 2.3 1.7 0.9 2.3 1.7 0.9 2.2 1.7 1.0 2.1 1.6 1.0
18 25 2.8 2.0 0.6 2.7 1.9 0.7 2.6 1.9 0.9 2.5 1.8 0.9 2.4 1.8 1.0 2.4 1.8 1.0
19 27 2.9 2.0 0.6 2.9 2.0 0.8 2.7 1.9 0.9 2.6 1.9 0.9 2.5 1.9 1.0 2.5 1.8 1.0
22 30 3.2 2.2 0.6 3.1 2.1 0.8 3.0 2.1 0.9 2.9 2.0 0.9 2.8 2.0 1.0 2.7 1.9 1.0
24 32 3.3 2.2 0.7 3.2 2.2 0.8 3.1 2.1 0.9 3.0 2.0 1.0 2.9 2.0 1.0 2.8 1.9 1.1
Indoor Air
Temperature
Outdoor Air Temperature : ˚ CDB
20 25 32 35 40 43
LS-J0962RL(PL)
˚CWB ˚CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 20 2.1 1.6 0.6 2.1 1.6 0.7 2.0 1.5 0.8 1.9 1.5 0.9 1.9 1.4 0.9 1.8 1.4 1.0
16 22 2.5 1.8 0.6 2.4 1.8 0.7 2.3 1.7 0.8 2.3 1.7 0.9 2.2 1.6 0.9 2.1 1.6 1.0
18 25 2.8 1.9 0.6 2.7 1.9 0.7 2.6 1.9 0.9 2.5 1.8 0.9 2.4 1.8 1.0 2.4 1.7 1.0
19 27 2.9 2.0 0.6 2.9 2.0 0.7 2.7 1.9 0.9 2.6 1.9 0.9 2.5 1.8 1.0 2.5 1.8 1.0
22 30 3.2 2.1 0.6 3.1 2.1 0.8 3.0 2.0 0.9 2.9 2.0 0.9 2.8 1.9 1.0 2.7 1.9 1.0
24 32 3.3 2.2 0.6 3.2 2.1 0.8 3.1 2.1 0.9 3.0 2.0 0.9 2.9 1.9 1.0 2.8 1.9 1.0
Indoor Air
Temperature
Outdoor Air Temperature : ˚ CDB
20 25 32 35 40 43
8.1 General Wall Mounted-Cooling
