Dimensional drawings6RMI0-02A
15
Inverter Single
Inverter Single
250(9.8)
1030(40.6)
325(12.8)
250(9.8)
Ø70(2.8)
Ø70(2.8)
69(2.7)
56(2.2)
Right rear piping
Left rear piping
Installation Plate
Measuring Tape
Measuring Tape
Hanger
Place a level on raised tab
Unit Outline
207(8.1)
105(4.1)
460(18.1) 570(22.4)
WALL MOUNTED
CHASSIS CODE : SC
4
[Unit: mm (inch)]
