Inverter SingleInverter SingleInverter Single
Capacity tables
DB°C(℉) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16(60.8) 2.38 0.67 2.51 0.65 2.72 0.68 2.90 0.73 3.22 0.78 3.41 0.82 3.70 0.87
18(64.4) 2.36 0.68 2.50 0.67 2.72 0.70 2.90 0.75 3.20 0.80 3.36 0.83 3.68 0.88
20(68) 2.34 0.69 2.50 0.69 2.72 0.72 2.89 0.77 3.17 0.82 3.34 0.85 3.69 0.88
21(69.8) 2.34 0.70 2.50 0.70 2.72 0.73 2.89 0.78 3.15 0.83 3.34 0.85 3.67 0.89
22(71.6) 2.33 0.71 2.50 0.70 2.72 0.74 2.88 0.79 3.13 0.83 3.34 0.86 3.64 0.89
24(75.2) 2.31 0.72 2.48 0.73 2.69 0.76 2.86 0.81 3.10 0.85 3.28 0.86 3.59 0.89
Outdoor Air Temperature : WB°C(℉)
-15(5) -10(14) -5(23) 0(32) 6(42.8) 10(50) 15(59)
Indoor Air
Temperature
AS-W093B1U1(LS091HSV)
DB°C(℉) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16(60.8) 2.93 0.86 3.09 0.84 3.34 0.88 3.57 0.95 3.96 1.01 4.19 1.06 4.55 1.12
18(64.4) 2.90 0.88 3.08 0.86 3.35 0.91 3.57 0.97 3.94 1.04 4.14 1.08 4.53 1.14
20(68) 2.88 0.89 3.08 0.89 3.35 0.93 3.56 1.00 3.90 1.06 4.11 1.09 4.54 1.14
21(69.8) 2.88 0.90 3.08 0.90 3.35 0.95 3.55 1.01 3.88 1.07 4.11 1.10 4.51 1.15
22(71.6) 2.87 0.91 3.08 0.91 3.35 0.96 3.54 1.03 3.85 1.08 4.10 1.11 4.47 1.15
24(75.2) 2.84 0.93 3.05 0.94 3.31 0.99 3.51 1.05 3.82 1.10 4.04 1.12 4.42 1.15
Outdoor Air Temperature : WB°C(℉)
-15(5) -10(14) -5(23) 0(32) 6(42.8) 10(50) 15(59)
Indoor Air
Temperature
AS-W123B1U1(LS121HSV)
DB°C(℉) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16(60.8) 4.45 1.39 4.68 1.36 5.08 1.42 5.42 1.53 6.02 1.64 6.36 1.70 6.90 1.81
18(64.4) 4.41 1.41 4.68 1.39 5.08 1.46 5.42 1.57 5.98 1.68 6.28 1.74 6.88 1.83
20(68) 4.38 1.44 4.67 1.43 5.09 1.51 5.40 1.61 5.92 1.71 6.24 1.76 6.89 1.85
21(69.8) 4.37 1.45 4.67 1.45 5.08 1.53 5.39 1.64 5.88 1.73 6.24 1.77 6.85 1.85
22(71.6) 4.36 1.47 4.68 1.47 5.08 1.55 5.38 1.66 5.84 1.74 6.23 1.78 6.79 1.85
24(75.2) 4.31 1.51 4.63 1.51 5.02 1.59 5.34 1.70 5.79 1.77 6.13 1.80 6.71 1.86
Outdoor Air Temperature : WB°C(℉)
-15(5) -10(14) -5(23) 0(32) 6(42.8) 10(50) 15(59)
Indoor Air
Temperature
AS-W163C2U1(LS161HSV)
DB°C(℉) TC PI TC PI TC PI TC PI TC PI TC PI TC PI
16(60.8) 4.85 1.40 5.10 1.37 5.53 1.43 5.91 1.54 6.56 1.65 6.93 1.71 7.52 1.82
18(64.4) 4.80 1.42 5.09 1.40 5.54 1.47 5.90 1.58 6.51 1.68 6.84 1.75 7.50 1.84
20(68) 4.77 1.45 5.09 1.44 5.54 1.52 5.89 1.62 6.45 1.72 6.80 1.77 7.51 1.86
21(69.8) 4.76 1.46 5.09 1.46 5.54 1.54 5.88 1.64 6.41 1.74 6.80 1.78 7.46 1.86
22(71.6) 4.75 1.48 5.09 1.48 5.54 1.56 5.86 1.67 6.36 1.75 6.79 1.79 7.40 1.86
24(75.2) 4.69 1.52 5.04 1.52 5.47 1.60 5.81 1.71 6.31 1.78 6.67 1.81 7.31 1.87
Outdoor Air Temperature : WB°C(℉)
-15(5) -10(14) -5(23) 0(32) 6(42.8) 10(50) 15(59)
Indoor Air
Temperature
AS-W183C2U2(LS181HSV)
7.2 Heating Capacity
Symbol Notes
AFR : Air flow rate [m
3
/min] 1. All capacities are net, evaporator fan motor heat is deducted.
DB : Dry bulb temperature [°C] 2. Indicates nominal maximum capacity.
WB : Wet bulb temperature [°C] 3. Direct interpolation is permissible. Do not extrapolate
TC : Total capacity [kW] 4. Capacities are based on the following conditions:
SHC : Sensible capacity [kW] - Interconnecting Piping Length 7.5m
PI : Power Input [kW] - Level Difference of Zero.
(Comp.+ indoor fan motor+outdoor fan motor) - Outdoor air : 85%RH. However, the condition on nominal capacity
is 7°CDB/6°CWB

LG AS-W093BRU1 Specifications

General

Brand	LG
Model	AS-W093BRU1
Category	Air Conditioner
Language	English
