Cooling mode operation
• Operating frequency of compressor depend on the difference of the temperature.
(= intake air Temp.- Compressor off Temp.
• Compressor off temp.= setting temp.
- 0.5°C
on temp. = setting temp. +0.5°C
• If compressor operates at some operating frequency, the operating frequency of compressor cannot be
changed within 30 seconds.
• Condition of compressor turned off
- When intake air temperature stay at the temperature between setting temp.
- 0.5°C and setting temp.
- 1.0°C for 3 minutes continuously.
- When intake air temperature reaches below the temperature of setting temp. - 1.0°C.
• Compressor 2 minutes delay
- The compressor can restart minimum 2 minutes later after compressor off.
Temp. differences Comp. Operating frequency
over 2.5°C Step 7
2.0~2.49°C Step 6
1.5~1.99°C Step 5
1.0~1.49°C Step 4
0.5~0.99°C Step 3
0.0~0.49°C Step 2
-0.5~0°C Step 1
[The operating freq. step of comp.]
[The targeting operating freq. of comp. each model]
Model
AS-W0964DH0/DH1/GH0 35 39 43 47 52 57 62
AS-W1264DH0/GH0 20 35 47 56 63 70 78
AS-W1865DH0 16 32 58 64 70 75 85
AS-W1224DH0 20 35 47 54 65 70 74
AS-W1424DH0 20 35 47 54 72 74 78
AS-W1825DH0 16 32 53 62 72 75 85
AS-W096E1G0 25 35 40 52 56 74 82
AS-W126E1G0 25 35 40 52 66 74 82
Comp. Operating frequency
Step 1 Step 2 Step 3 Step 4 Step 5(Fc) Step 6 Step 7
Healthy Dehumidification mode operation
• When the dehumidification operation is set by the remote controller the intake air temperature is detected and
the setting temp. is automatically set according to the intake air temperature.
• When intake air temp reaches above the temp of setting +1.0°C, condition of compressor same as cooling
mode operation.
• When intake air temperature reaches bolow the temp of setting –1.0°C, compressor operate step1~step3 and
indoor fan speed repeatly operate low or stop.
Intake air Temp.
26°C ≤ intake air temp.
24°C ≤ intake air temp.< 26°C
18°C < intake air temp. < 24°C
intake air temp. ≤ 18°C
Setting Temp.
25°C
intake air temp. -1°C
intake air temp. -0.5°C
18°C
Operation

LG AS-W096E1G0 Specifications

General

Brand	LG
Model	AS-W096E1G0
Category	Air Conditioner
Language	English
