SIGNAL RESOLUTION
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE COMPONENT RGB
720p 37.5 50 — O —
720p 45.0 60 — O —
1080i 33.8 60 — O —
HDTV
1080i 28.1 50 — O —
*2 VGA modes: 640 x 350 @70Hz/ 640 x 350 @85Hz show up will mainly depends on DDP2431. It
will display either 640 x 400 or 640 x 480. As for vertical Sync, it will follow each mode’s frequency
accordingly.
#2 VGA modes: 1400 x 1050 @60Hz this DPI for system constrain.
O: Frequency supported
—: Frequency not supported
* : Displayable level
The resolution of the panel for the BS274 is 800 x 600, 1024 X 768 is for BX274 and BX324.
Resolution other than native resolution may display with uneven size of text or lines.
HDTV timing: DVD player (main source), VG828 (secondary source).
