LG CJ45 - Main & SMPS Board Removal

2-12
1
3
2
2
Figure 4
4. MAIN Board & SMPS Board
4-1) Remove the 9 Screws from the MAIN Board & SMPS Board.
4-2) Remove the 6 Cables from the MAIN Board.
4-3) Remove the Power Cord from the SMPS Board.
4-4) Remove the MAIN Board & SMPS Board.
