Part 2 Functions & Controls
Category Functions
AUUW426D2
[UU42W U32]
AUUW486D2
[UU48W U32]
AUUW606D2
[UU60W U32]
Reliability
Defrost / Deicing O O O
High pressure switch X X X
Low pressure switch X X X
Phase protection X X X
Restart delay (3-minutes) O O O
Self diagnosis O O O
Soft start O O O
Test function X X X
Convenience Night Silent Operation O O O
CAC network
function
Network soluation(LGAP) O O O
Device
AUUW426D2
[UU42W U32]
AUUW486D2
[UU48W U32]
AUUW606D2
[UU60W U32]
Central
Controller
Simple Controller
Function controller
Function Scheduler
AC Ez
AC Smart ll
Option Kit (SD card type)
ACP(Advanced Control Platform)
AC Manager
PI485
DO(Digital Output) Kit
BNU (Building
Network Unit)
LONWORKS Gateway
BACnet Gateway
Installation
Y branch
Header branch
Air Guide
ODU Dry Contact
Low Ambient Kit
[Note]
• O: Applied, • X: Not applied
Accessory model name : Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate
package.
PQCSB101S0 PQCSB101S0 PQCSB101S0
PQCSB101S0 + PQCSC101S0 PQCSB101S0 + PQCSC101S0 PQCSB101S0 + PQCSC101S0
PQCSB101S0 + PQCSD130A0 PQCSB101S0 + PQCSD130A0 PQCSB101S0 + PQCSD130A0
PQCSZ250S0 PQCSZ250S0 PQCSZ250S0
PQCSW320A1E PQCSW320A1E PQCSW320A1E
PQCSE341A0 / PQCSE342A0 PQCSE341A0 / PQCSE342A0 PQCSE341A0 / PQCSE342A0
PQCPA11A0E / PQCPB11A0E PQCPA11A0E / PQCPB11A0E PQCPA11A0E / PQCPB11A0E
PQCSS520A0E PQCSS520A0E PQCSS520A0E
PMNFP14A0/PMNFP14A1 PMNFP14A0/PMNFP14A1 PMNFP14A0/PMNFP14A1
PQNFP00T0 PQNFP00T0 PQNFP00T0
PQNFB16A1 PQNFB16A1 PQNFB16A1
PQNFB17B0 PQNFB17B0 PQNFB17B0
XXX
XXX
XXX
O (On/off control) O (On/off control) O (On/off control)
O (Logical operation) O (Logical operation) O (Logical operation)
