General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. 206.0 mm x 315.0 mm x 284.0 mm
(Approx. 8.11 inch x 12.40 inch x 11.18 inch)
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Inputs
Analog audio in (AUX IN 2) 0.6 Vrms, 75 Ω, RCA jack (L,R)
Portable in (AUX IN 1) 0.6 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 70 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 75 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 700 W RMS
Front 230 W RMS X 2 (3 Ω at 1 kHz, 20 % THD)
Subwoofer 240 W RMS (3 Ω at 60 Hz, 20 % THD)
y Design and specications are subject to change without notice.
