LG CM8530 - Appendix; General Specifications

5 Appendix
Appendix 33
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 285 mm x 398 mm x 357 mm
Net Weight (Approx.) 8.2 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply USB DC 5 V
0
500 mA
Inputs
Auxiliary Input 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
Microphone Input 6.3 mm jack
Portable Input 1.2 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Model CM8530 CM8430 CM8330
Stereo mode 360 W x 2 (THD 10 %) 400 W x 2 (THD 10 %) 400 W x 2 (THD 10 %)
Surround
mode
Front 360 W x 2 (THD 10 %) 400 W x 2 (THD 10 %) 400 W x 2 (THD 10 %)
Surround 180 W x 2 (THD 10 %)
Subwoofer 360 W x 2 (THD 10 %) 400 W (THD 10 %)
