ELECTRICAL TROUBLESHOOTING GUIDE
4. NO LIGHTING (WOOFER SPEAKER)
YES
YES
CD / USB play
Check IC501.
Check woofer speaker.
Check SMPS board.
NO
NO
CNWM02,
CNWS01 Pin3, 4 I2C signal
OK?
Pin1 +12 V OK?
