LG CM9730 - General Specifications

Appendix32
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 542 x 308 x 421 mm
Net Weight (Approx.) 9.85 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply USB DC 5 V
0
500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 600 , RCA jack (L, R) x 1
PORT. IN 1.2 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
Amplier
Output 575 W x 4 (8  at 1 kHz, THD 25 %)
Front speaker
Type
Low channel 1 Way 1 speaker
High channel 2 way 2 speaker
Impedance 8 
Rated Input Power 575 W
Max. Input power 1150 W
Net Dimensions (W x H x D) 520 x 720 x 499 mm
Net Weight 35.5 kg
y
Design and specications are subject to change without notice.
