LG CMS1530F - Circuit Voltage Chart; Ics; Diodes; Capacitors

3-35 3-36
CIRCUIT VOLTAGE CHART
1. ICs 3. CAPACITORS
Pin No. Specifi cation 80 V / 60 Hz Input 288 V / 50 Hz Input
IC102 MFI337S3959 (IP)
5(VCC) 2.7~3.6V 3.28 3.28
IC103 CA6818 (MCU IC)
5(VCC) 2.7~3.6V 3.28 3.26
23(VCC) 2.7~5.5V 3.28 3.26
IC105 CM1117 (Regulator IC)
3(VIN) 4.3~12V 5.08 5.1
2(VOUT) 4~0.15V 3.28 3.28
IC301 SM1616 (DISPLAY DRIVE IC)
25(VDD) 3~5V 3.32 3.32
IC503 LM39102D (Regulator IC)
2(VIN) 0.3~22V 5.02 5.02
3(VOUT) 0.3~22.3V 4.92 4.92
IC700 LM29152 (Regulator IC)
1(VIN) ≤26V 7.28 7.26
3(VOUT) 5V±0.25V 5.21 5.21
IC701 MC4558 (SOUND AMP)
4(VCC-) ±22V 0 0
8(VCC+) ±22V 9.06 9.06
IC702 TDA7266SA (AMPLIFIER IC)
3(VCC) 3~18V
play:11.27V
mute:11.48V
standby:9.9V
play:11.27V
mute:11.47V
standby:9.9V
13(VCC) 3~18V
play:11.24V
mute:11.48V
standby:10.8V
play:11.24V
mute:11.48V
standby:10.8V
6(MUTE) 0~18V
play:5.18V
mute:0V
standby:0V
play:5.18V
mute:0V
standby:0V
7(ST-BY)
play,mute:4-5v
standby:0-1v
play:4.47V
mute:4.47V
standby:0V
play:4.47V
mute:4.47V
standby:0V
IC703 BD3490FV (SOUND CONTROL)
24(VCC) 4.7-9.5V 9.06 9.06
IC800 CD5888 (MOTOR DRIVE IC)
8(VCC) 4.5~9V 5.18 5.18
19(VCC) 4.5~9V 5.18 5.18
IC801 M5677 QPFP-128 (Audio decode IC)
8(AVDD33_2) 3.0~3.6V 3.33 3.33
18(AVDD33_3) 3.0~3.6V 3.33 3.33
25(AVDD33_LDO) 3.0~3.6V 3.33 3.33
26(AVDD18_LDO) 1.6~1.9V 1.78 1.78
27(AVDD18_RTC) 1.6~1.9V 1.78 1.78
34(AVDD18_1) 1.6~1.9V 1.78 1.78
39(AVDD18_ADO) 3.0~3.6V 3.33 3.33
50(VDD-CORE) 1.6~1.9V 1.78 1.78
53(VDD-PAD) 3.0~3.6V 3.33 3.33
2. DIODES
No. Type
80 V / 60 Hz Input 288 V / 50 Hz Input
Spec.
Positive
(+)
Negative
(-)
Positive
(+)
Negative
(-)
D901 IN5399 0V 42V 0V 160V
1000V
(Reverse)
D902 IN5399 0V 42V 0V 160V
1000V
(Reverse)
D903 IN5399 42V 105V 159V 386V
1000V
(Reverse)
D904 IN5399 42V 105V 159V 386V
1000V
(Reverse)
D905 FR107 106V 199V 420V 478V
1000V
(Reverse)
D906 FR107 0 17.23V 0V 17V
1000V
(Reverse)
D907 HER303 0V 10.4V 0V 10.32V
200V
(Reverse)
D908 DR107 0V 12.58V 0 12.51V
1000V
(Reverse)
D909 SR360 0V 5.23V 0V 5.23V
30V
(Reverse)
D910 HER303 0V 13.37V 0V 13.3V
200V
(Reverse)
ZD901 18V 0 17.23V 0 17V
15V±5%/
0.5W
ZD902 9.1V 0V 0.5V 0V 0.5V
9.1V±5%/
0.5W
Pin No. Specifi cation 80 V / 60 Hz Input 288 V / 50 Hz Input
86(VDD-PAD) 3.0~3.6V 3.33 3.33
114(VDD-PAD) 3.0~3.6V 3.33 3.33
116(VDD-CORE) 1.6~1.9V 1.78 1.78
122(AVDD33_1) 3.0~3.6V 3.33 3.33
IC802 EON 2M FLASH SOP-8 (FLASH)
8(VCC) 2.7~3.6V 3.33 3.32
IC902 WL431
1 REF:2.44~36V 2.41V/2.41V
2 GND:0V 0/0v
3 VZ:-0~37V 3.89V/3.88V
TU401 YST990-A3U0 (FM/AM MODE) (Tuner Module )
1(VDD) 5V+/-0.5 4.82 4.82
U400 YST995-H2U0 (FM MODE) (Tuner Module )
1(VDD) 3V+/-0.3 3.02 3.02
U400 YST995-H4C0 (FM/RDS MODE) (Tuner Module )
1(VDD) 3V+/-0.3 3.02 3.02
No.
288 V / 50Hz Input Engineering Check
Value (uF) Voltage Spec. Positive (+)
SMPS Board
C904 47uF 50V 16.94 V
C906 1000uF 25V 10.21 V
C908 1000uF 25V 10.25 V
C911 220uF 25V 12.42 V
C913 220uF 25V 12.4 V
C916 1000uF 16V 5.23 V
C918 1000uF 16V 5.23 V
C922 1000uF 16V 13.97 V
C924 1000uF 16V 13.64 V
C928 68uF 450V 386 V
MAIN Board
C411 100uF 16V 3.14 V
EC102 22uF 16V 1.68 V
EC103 22uF 16V 3.29 V
EC110 22uF 16V 3.3 V
EC111 220uF 10V 3.3 V
EC400 47uF 16V 1.24 V
EC401 47uF 16V 3.29 V
EC402 47uF 16V 5.18 V
EC700 100uF 16V 8.99 V
EC703 22uF 16V 4.48 V
EC705 220uF 25V 4.74 V
EC706 47uF 16V 9.02 V
EC708 1000uF 25V 10.24 V
EC709 220uF 16V 5.11 V
EC710 220uF 16V 5.21 V
EC711 47uF 16V 11.54 V
EC712 220uF 10V 5.21 V
EC713 220uF 16V 13.09 V
EC714 220uF 16V 11.58 V
EC715 47uF 16V 0.73 V
EC716 220uF 16V 5.21 V
EC805 100uF 16V 3.34 V
EC807 47uF 16V 1.77 V
EC809 10uF 16V 1.57 V
EC810 47uF 16V 5.16 V
EC811 100uF 16V 5.14 V
EC812 47uF 16V 1.35 V
EC813 220uF 10V 3.3 V
EC814 470uF 10V 5.09 V
