LG CMS1530F - Connectors

3-37 3-38
4. CONNECTORS
No. Pin No.
240 V / 50 Hz Input
Specifi cation Value
SMPS Board
CN901
1PIN IPOD GND 0V 0V
2PIN IPOD +6.2v 5.5V~10.5V 7.64V
3PIN GND 0V 0V
4PIN +12V 12V±2.5 12.43V
5PIN GND 0V 0V
6PIN +5.2V 5.2±0.2 5.18V
6PIN +5.2V 5.2±0.2 5.18V
7PIN PGND 0V 0V
8PIN PGND 0V 0V
9PIN PVDD 10±2.5 10.21V
10PIN PVDD 10±2.5 10.21V
MAIN Board
CN700
1PIN IPOD +6.2V 5.5V~10.5 7.59V
2PIN IPOD GND 0V 0V
3PIN GND 0V 0V
4PIN +12V 12V±2.5 12.38V
5PIN GND 0V 0V
6PIN +5.2V 5.2±0.2 5.18V
6PIN +5.2V 5.2±0.2 5.18V
7PIN PGND 0V 0V
8PIN PGND 0V 0V
9PIN PVDD 10±2.5 10.2V
10PIN PVDD 10±2.5 10.2V
CON101
1PIN IR 20±0.5V 3.24V
2PIN VOL- 0-3.3V 0.33V
3PIN VOL+ 0-3.3V 0.33V
4PIN KEY 0-3.3V 3.28V
5PIN MAINPOWER 0-3.3V 0V
6PIN GND 0V 0V
7PIN LCD_DATA 0-3.3V 0.3V
8PIN LCD_STB 0-3.3V 3.28V
9PIN LCD_CLK 0-3.3V 3.28V
10PIN VCC 3.3V 3.28V
No. Pin No.
240 V / 50 Hz Input
Specifi cation Value
CON803
1PIN SP+ 0-2.8V 2.91V
2PIN SP- 0-2.8V 2.07V
3PIN SL- 0-2.8V 2.59V
4PIN SL+ 0-2.8V 2.42V
5PIN LIMIT 0-3.3V 3.31V
6PIN GND 0V 0V
No. Pin No.
240 V / 50 Hz Input
Specifi cation Value
CON102
1PIN IPOD-L 0-0.9 0.15V
2PIN IPOD-GND 0V 0V
3PIN IPOD-R 0-0.9 0.15V
4PIN IPOD-DET 0-3.3 0V
5PIN ACC-DET 0-3.3 3.16V
6PIN ACC-PWR 0-3.3 3.03V
7PIN IPOD-TX 0-3.3 3.03V
8PIN IPOD-RX 0-3.3 3.28V
9PIN IPOD-5V 5±0.25 5.13V
10PIN IPOD-5V 5±0.25 5.13V
11PIN IPOD-GND 0V 0V
12PIN IPOD-GND 0V 0V
13PIN IPOD-GND 0V 0V
CON107
1PIN AUX_R 0-0.9V 0.15V
2PIN AUX_G 0V 0V
3PIN AUX_L 0-0.9V 0.15V
4PIN AUX_DET 0-3.3V 0V
6PIN USB_5V 5±0.25V 5.05V
7PIN USB_D- 0-5V 3.1V
8PIN USB_D+ 0-5V 0.2V
8PIN USB_GND 0V 0V
CON800
1PIN DROP-DET 0-3.3V 0V
2PIN GND 0V 0V
CON801
1PIN HAVC 0-3.3V 1.59V
2PIN VCC 0-3.3V 3.32V
3PIN E 0-3.3V 2.06V
4PIN D 0-3.3V 1.89V
5PIN A 0-3.3V 1.82V
6PIN B 0-3.3V 1.92V
7PIN C 0-3.3V 2.06V
8PIN F 0-3.3V 1.89V
9PIN GND 0V 0V
10PIN LD 0-3.3V 1.86V
11PIN VR 0-3.3V 0V
12PIN MD 0-3.3V 0.2V
13PIN F+ 0-2.8V 2.53V
14PIN T- 0-2.8V 2.42V
15PIN T+ 0-2.8V 2.6V
16PIN F- 0-2.8V 2.41V
