17
INSTALLATION
ENGLISH
In order to assemble as mounting the fixed panel,
the sliding links must be disassembled. Remove
the sliding links by loosening the 2 screws on each
left and right.
• When disassembling the link assembly, be sure
to wear gloves as there is a risk of injury.
• When reassembling the link assembly, door
malfunction may occur, call qualified service
personnel for installation and service.
Checking the Level
Levelling the appliance prevents unnecessary
leakage and poor washing. Check whether the
appliance is perfectly level after installation.
• If the appliance rocks when pushing the top
plate of the appliance diagonally, adjust the feet
again.
• The appliance is not level if there is a rubbing
sound or stickiness when the door is opened.
Adjusting and Leveling the
Appliance
When the appliance is not perfectly level, turn the
adjustable feet until the appliance no longer
wobbles.
• Place the appliance on a solid, level floor.
• Do not install the appliance on an elevated
surface.
Adjusting Front Levelling Feet
• Use a flat-blade screwdriver to turn the front
levelling feet and adjust the front of the tub.
• Turn the front levelling feet clockwise to raise the
front of the tub up to 60 mm
a
and
counterclockwise to lower it up to 60 mm
a
.
• The adjustments work identically for both front
levelling feet.
Adjusting Back Levelling Feet
• Use a phillips screwdriver to adjust the rear
levelling foot and the rear of the tub using the
centre screw at the base of the appliance in the
front.
