13-2. Panel Drawer Assembly & Guide Assembly
K503 K508
K501
A090
A172
A171
A350
K507
K505
K502
A160
A170
K504
K506
A161
13
EXPLODED VIEW
13-1-1. Control Panel & Plate Assembly (Touch LCD type)
A130
A210
A211
A120
A140
A110
A150
※ In case before April,2015 Production.
If Part Assembly (AGM75370001) is replaced,
- Main, PCB(A130)
- Display, PCB(A120) have to be replaced
all together.
