LG DLEX3470V - Reversing the Door

16
1. Open the door to reverse.
2. Check screws to remove (Left 4, Right 2).
3. Remove four dummy screws by driver.
Reversing the door
4. Remove two screws and disassembly latch.
5. Hold on the hinge while remove 2 screws of hinge (to prevent
door dropping).
6. Remove door from cabinet cover.
Hinge
Dummy
Screw
Open Door
Remove
Door
Hinge Screw
Latch Screw
INSTALLATION INSTRUCTIONS
w
WARNING







THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure to follow
the instructions below can result in damage to the dryer,
property damage or injury to persons.
