16
Clearances with Optional Pedestal Base
RECOMMENDED INSTALLATION SPACING FOR CABINET INSTALLATION
t'PSDBCJOFUJOTUBMMBUJPOXJUIBEPPSNJOJNVNWFOUJMBUJPOPQFOJOHTJOUIFUPQPGUIFDBCJOFUBSFSFRVJSFE
*Required spacing
** For side or bottom venting,
2 inches (5.1 cm) spacing is allowed.
7"* (17.8 cm)
9"*
(22.9 cm)
7"* (17.8 cm)
5"**
(12.7 cm)
27’’
(68.6cm)
1"*
(2.5 cm)
(2.5 cm)
(2.5 cm)
30’’
(76.2cm)
INSTALLATION
