LG DLGX 3251 Series User Manual

46 47
1.
Open the top plate.
2.
Remove Cover Cabinet.
3.
Disconnect the door lamp and electrode
sensor connector.
4.
Remove 4 screws.
5.
Disassemble the Tub Drum (Front) assembly.
TUB DRUM [FRONT]
1.
Open the top plate.
2.
Remove the Cabinet Cover and
Tub Drum (Front) assembly.
3.
Loosen belt from motor and idler pulleys.
4.
Carefully remove the drum.
DRUM ASSEMBs
-1
-2
-1
1.
Open the door.
2.
Hold the lamp shield in place while removing the
screw.
3.
Slide the shield up and remove.
4.
Remove the bulb and replace with a 15-watt, 120-volt
candelabra-base bulb.
5.
Replace the lamp shield and screw.
CHANGING THE DRUM LAMP
When you disassemble the lamp connector, be
sure to take gloves and handle the frame and
other parts carefully to avoid cuts. Failure to do
this could lead to a serious injury.
H
WARNING !
