LG E1941S - DPM Fault Diagnosis


Copyright © 2011 LG Electronics. Inc. All right reserved. - 22 - LGE Internal Use Only
Only for training and service purposes
4. TROUBLE IN DPM
Trouble in DPM
Scaler IC
pin 14 H Sync?
pin 15 V Sync?
Check H/V sync line
Trouble in cable or LCD
module
NO
YES
