2 Fix the cable management with cable management
screw.
M4 x L10
2 EA
NOTE
When attaching the cable management, use
a magnetic screwdriver.
If you don’t have a magnetic screwdriver,
insert the screws into the cable management
and then attach it to the TV.
3 Gather and bind the cables with the cable holder.
Arrange the cable in the cable mangement.
Cable Management
Cable Holder
(Only EC98**)
Gather and bind the cables with the cable holder.
Cable Holder
Wall Mount Type
(Only EC93**, EC94**, EC90**)
Cable Holder
CAUTION
Do not move the TV by holding the cable
holder, as the cable holder may break, and
injuries and damage to the TV may occur.
25
