ERROR SYMPTOM CAUSE
8
9
• The connector in the LEAD WIRE ASSEMBLY is not connected to
the connnector of STATOR ASSEMBLY
Reconnect or repair the connector
• The hall sensor is out of order/defective.
Replace the STATOR ASSEMBLY
• The Dry Heater is out of order
Replace the Dry Heater
• The Connector of the Dry Heater is not connected properly to the
connector in the Main PWB ASSEMBLY
Reconnect or repair the connector
• The Dry fan motor is out of order
Replace the fan Motor.
MOTOR
ERROR
DRY
HEATOR
ERROR
16
• Loose Ball Sensor Connector.
• Ball Sensor is out of order.
※ Displayed only when the START/PAUSE button is first
pressed in the QC Test Mode.
10
BALL
SENSOR
ERROR
•
The washer experienced a power failure.
12
POWER
FAILURE
• EEPROM is out of order.
※ Displayed only when the START/PAUSE button is first
pressed in the QC Test Mode.
11
EEPROM
ERROR
