HOW TO ASSEMBLE THE MOTOR
①①
Open the door.
②②
Remove the two screws from the Hinge.
※ When removing the Door Assembly, it is necessary
to hold the Bracket that is inner of the cabinet cover.
①①
Open the door and disassemble the CLAMP
ASSEMBLY.
②②
Unscrew the 2 screws.
※※
Be careful! The door is heavy.
※※
NOTE
• Reconnect the connector after replacing the
DOOR SWITCH ASSEMBLY.
To Next Page
