37
WHEN FOREIGN OBJECT IS STUCK BETWEEN DRUM AND TUB
①①
Disassemble the cabinet cover.
②②
Separate the heater from the tub.
③③
Remove any foreign objects (wire, coin, etc.) by
inserting a long bar in the opening.
MOTOR/DAMPER
①①
Disassemble the back cover.
②②
Remove the bolt.
③③
Pull out the Rotor.
①①
Unscrew the 2 screws from the tub bracket.
②②
Remove the 6 bolts on the stator.
③③
Unplug the 2 connectors from the stator.
①①
Disassemble the damper hinges from the tub
and base.
②②
Separate the dampers.
※※
NOTE
• Before removing the hinge, press the hook.
And then replace the damper with new one.
