LG F1480RD User Manual

22
■ Control panel
Start/Pause
button
Option
buttons
Beep
On/Off
Power
button
Dry dial
Tub
Clean
Temp.
button
Spin
button
Child
Lock
Additional program
buttons
LED display
Program
dial
Power
• Press the Power button to turn power on
and off.
• To cancel the Time Delay function, the
power button should be pressed.
Program dial
• Programs are available according to the
laundry type.
• Lamp will light up to indicate selected
program.
Additional program
• Use these buttons to select the desired
cycle options for the selected cycle.
LED display
• The display shows the settings, estimated
time remaining, options, and status
messages for your washer.
The display will remain on through the
cycle.
Start/Pause
• This Start/Pause button is used to start
wash cycle or pause the wash cycle.
• If temporary stop of wash cycle is
needed, press the Start/Pause button.
• When in Pause, the power is turned off
automatically after 4 minutes.
Options
• This allows you to select an additional
cycle and will light when selected.
SMARTDIAGNOSIS™ function is
available only for the products with
a SMARTDIAGNOSIS™ mark.
How to use washer

LG F1480RD Specifications

General

Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	95 L
Energy consumption washing & drying per cycle	7.29 kWh
Washing class	A
Drum volume	65 L
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	19 h
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	69 dB
Number of washing programs	13
Door opening angle	170 °

Weight and Dimensions

Depth	640 mm
Width	600 mm
Height	850 mm
Weight	72000 g
Door opening diameter	350 mm
