Dry Fan Motor Trouble
Is the Connector connected correctly to
the Main PCB and the Dry Heater or Fan Motor ?
Or is the Harness alright?
Are the resistance same between terminal points?
V~U / U~W / W~V : 2~5Ω
When checking voltage between connectors(1,2)
on drying, is the voltage DC 20~30V as the figure ?
YES
YES
Reconnect or repair the Connector.
Or replace the Harness.
NO
Replace the Dry Fan Motor.
NO
Replace the PWB assembly
(main).
NO
VUW
To Next Page
