10
Please use the horizontal tap
Horizontal tap
Extension tap
Square tap
1. Unscrew the adapter ring plate and the 4 adapter retaining
screws.
2. Remove the guide plate if the tap is too large to fit the
adapter.
3. Push the adapter onto the end of the tap so that the rubber
seal forms a watertight connection.
Tighten the adapter ring plate and the 4 screws.
4. Pull the connector latch plate down, push the inlet hose onto
the adapter, and release the connector latch plate.
Make sure the adapter locks into place.
Ring plate
Guide plate
Latch plate
Type-C : Connecting one touch type hose to tap without thread
Step3: Connect hose to washer
• Make sure that there are no kinks in the hose and that they are not
crushed.
When your washer has two valves.
• The Inlet hose With the red connector is for the hot water tap.
• If the washer has two valves, energy is saved by using the hot valve.
NOTE
After connecting inlet hose to water tap, turn on the water taps
to flush out foreign substances (dirt, sand or sawdust) in the
water lines. Let water drain into a bucket, and check the water
temperature.
NOTE
After completing connection, if water leaks from the hose, repeat the same steps.
Use the most conventional type of faucet for water supply. In case the faucet is square or too big, remove the spacing
ring before inserting the faucet into the adaptor.
