Motor Locked Error (LE)
[Pre Check]
Gentle wash cycles, such as Perm Press, Delicates, Hand Wash, and Wool/Silk should only be used for smaller loads.
Because these cycles are more gentle in tumbling and spinning, putting too much in the drum can register an issue
with the motor. Remove items, reset unit and test with a Rinse/Spin cycle.
Is the Connector connected correctly to
the Main PCB and the Motor?
Is the Harness alright ?
YES
NO
YES
YES
NO
Disassemble the Rotor.
Is the Magnet of rotor cracked or broken?
Press the Power button & Start / Pause button.
Does the Drum stop when the start/pause button is pressed to start the cycle ?
Or Sometimes does the Drum rotateweakly (under 15rpm)?
Reconnect or repair the Connector .
Or replace the Harness .
Replace the Rotor .
Is the resistance the same
betweenStator points?
V~U / U~W / W~V : 8~11Ω
V U W
NO
Replace the Stator .
V U W
YES
Replace the Main PCB .
To Next Page
