- 7 -
2. FA-P3000 (AMP)
3. FA-P3000 (DSP)
IC320 (STK402-930) IC151 (TDA7294)
PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V)
1 -0.12V 16 -0.13V 1 -1.8mv
2 -0.13V 17 -0.13V 2 -0.4mv
3 -0.12V 18 -24.4V 3 -1.5mv
4 -0.12V 19 -0.13V 4 -1.8
mv
5 -15.4mv
20 -0.13V 5 -0.3V
6 -13.3mv
21 -0.12V 6 15.55V
7 28.6V 22 -0.13V 7 29.1V
8 -28.7V 23 -11.4
mv 8 -29V
9 -28.7V 24 -25.8V 9 4.9V
10 28.7V 10 4.9V
11 12.6mv 11 2.2mv
12 -9.2mv 12 6.8mv
13 25.8V 13 29.2V
14 -2.3mv 14 -0.7mv
15 -25.5V 15 -29.3V
IC201 (CS4228A) IC202 (CS8415)
PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V)
1 0.58V 16 2.11V 1 0.12V 16 1.63V
2 34.8mv 17 2.11V 2 88.8mv 17 1.64V
3 0.94V 18 3.56V 3 8
mv 18 25.7mv
4 1.23V 19 2.17V 4 7.6
mv
19 2.9V
5 1.61V 20 2.17V 5 7.6mv 20 25.3mv
6 1.64V 21 4.92V 6 4.93V 21 1.7V
7 5.5mv 22 4.6mv 7 7.6mv 22 24.6mv
8 3.27V 23 2.28V 8 7.6mv 23 3.28V
9 3.28V 24 2.29V 9 3.27V 24 24.6
mv
10 1.51V 25 2.28V 10 1.50V 25 24.6mv
11 13.8mv 26 2.29V 11 26.4mv 26 24.6mv
12 0.12V 27 2.28V 12 0.25V 27 0.11V
13 3.27V 28 2.29V 13 24.5mv 28 13.7mv
14 3.26V 14 24.5
mv
15 3.28V 15 24.5mv
