- 8 -
IC800 (UPD16311)
PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V)
1 1.72V 16 -25.8V 31 -24V 46 5.0V
2 1.70V 17 -19.5V 32 -23.9V 47 5.0V
3 1.70V 18 -25.8V 33 5.0V 48 5.0V
4 1.70V 19 -23.7V 34 -26.2V 49 5.0V
5 1.70V 20 -25.8V 35 -23.9V 50 5.0V
6 4.58V 21 -12.6V 36 -23.9V 51 1.0mv
7 4.95V 22 -15.2V 37 -23.9V 52 2.72V
8 4.88V 23 -19.4V 38 -23.9V
9 4.58V 24 -21.5V 39 -23.9V
10 1.77V 25 -13.1V 40 -23.9V
11 1.77V 26 -17.3V 41 -23.9V
12 1.76V 27 -26V 42 -23.9V
13 1.72V 28 -23.9V 43 -23.9V
14 4.95V 29 -26V 44 -24.1V
15 -25.5V 30 -17.4V 45 5.0v
IC101 (KIA4558F) IC151 (A4558F) IC301 (KIA4558F) IC401 (KIA4558F) 8)IC501 (KIA4558F)
PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V)
1 5.7mv 1 5.7mv 1 14.5mv 1 11.4mv 1 11.2mv
2 6.2mv 2 6.0mv 2 10.1mv 2 8.6mv 2 8.4mv
3 5.4mv 3 5.4mv 3 9.6mv 3 8.5mv 3 8.4mv
4 -5.23V 4 -5.23V 4 -6.07V 4 -6.07V 4 -6.07V
5 5.5mv 5 5.4mv 5 9.6mv 5 8.6mv 5 8.7mv
6 5.9mv 6 5.3mv 6 10.4mv 6 9.2mv 6 9.2mv
7 5.4mv 7 4.2mv 7 15.1mv 7 12.8mv 7 12.7mv
8 5.09V 8 5.08V 8 5.92V 8 5.92V 8 5.92V
4.FA-P3000 (Fornt)
IC201 (CS493264)
PIN NO. Volt(V) PIN NO. Volt(V) PIN NO. Volt(V)
1 2.48V 16 2.58V 31 7.9mv
2 25.2mv 17 2.58V 32 2.07V
3 0.94V 18 2.58V 33 1.3V
4 2.47V 19 0.12V 34 2.59V
5 25.1mv 20 3.29V 35 7.9mv
6 2.58V 21 2.58V 36 3.27V
7 4.2mv 22 9.2
mv 37 21.3
mv
8 2.58V 23 2.58V 38 2.58V
9 2.58V 24 8.1
mv
10 2.58V 25 1.62V
11 2.58V 26 1.65V
12 2.58V 27 1.24V
13 8.0mv 28 1.62V
14 2.58V 29 1.66V
15 2.58V 30 1.7V
