11
Designs and specifications are subject to change without notice.
Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3,2 kg
External dimensions (WxHxD) 175 x 217 x 260 mm
Operating temperature 5
o
C to 35
o
C
Operating humidity 5% to 85 %
Tuner
FM Tuning Range 87,5 - 108,0 MHz or 65 - 74 MHz,
87,5 - 108,0 MHz
AM Tuning Range 522 - 1620 kHz or 520 - 1720 kHz
Amplifier
Output Power 80 W + 80 W
T.H.D 0,5 %
Frequency Response 40 - 20000 Hz
Signal-to-noise ratio 75 dB
CD
Frequency response 40 - 20000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 75 dB
Speakers (FAS163F)
Type 3 Way 3 Speaker
Impedance 4 Ω
Frequency Response 70 - 20000 Hz
Sound Pressure Level 83 dB/W (1m)
Rated Input Power 80 W
Max. Input Power 160 W
Net Dimensions (WxHxD) 129 x 297 x 250 mm
Net Weight (1EA) 3,6 kg
Troubleshooting
Symptom Cause Correction
General
No power.
No sound.
The power cord is not plugged in.
Check whether electricity failed.
Check whether you select right function.
Plug in the power cord.
Check the condition by operating other
electronic devices.
Press FUNC. (FUNCTION/INPUT) and
check the selected function.
CD
The unit does not
start playback.
An unplayable disc is inserted.
The disc is dirty.
Insert a playable disc.
Clean the disc.
RADIO
Radio stations
cannot be tuned in.
The antenna is positioned or connected
poorly.
Connect the antenna securely.
Remote control
The remote control
does not work
properly.
The remote control is too far from the
unit.
There is an obstacle in the path of the
remote control and the unit.
The battery in the remote control is
exhausted.
Operate the remote control within about
16 ft (5 m).
Remove the obstacle.
Replace the battery with new one.
