LG Flatron L1710B

DATE: 2002. 10. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C817 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C818 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C819 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C840 0CE477EH618 470UF KMG 25V M FL TP 5
C845 0CE477EH618 470UF KMG 25V M FL TP 5
C860 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D703 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D704 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D709 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D710 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D711 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
D712 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D714 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D716 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D717 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D718 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D719 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D720 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D721 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D722 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D732 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D733 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D734 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D735 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D736 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D737 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D738 0DZ845109AB BZX84C5V1 TP G.I SOT23 0.35W 5
D739 0DZ845109AB BZX84C5V1 TP G.I SOT23 0.35W 5
ZD701 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD702 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD703 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD704 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD705 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD706 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD707 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD708 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD709 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD710 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD711 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
U106 0IRH765700B BA7657F 24P,SOP TP INPUT SIG.
U107 0ISTLTI040A SN74AHC1G86DBVR TEXAS INSTRUME
U108 0IPH740800H 74F08D 14P,SOIC TP QUAD 2-INPU
U109 0TFFC80009A FAIRCHILD FDC6326L R/TP SOT-6
U110 0ISS780500H KA78M05-R 3P,D-PAK TP 5V 0.5A
U201 0IZZTSZ214A ATMEL/STM 32PIN ST OTP LB700K
U203 0IPRPGN005A GM5120 GENESIS 208P,PQFP TRAY
U205 0IMMRSS040C S524A60X51(SCT0) SAMSUNG ELECT
U207 0IKE702900D KIA7029AP TO-92 TP 2.9V DETECT
U401 0ILNRTH001A THC63LVD823 THINE MICROSYSTEMS
U701 0ISS524202B S524A40X21(SCT0) SAMSUNG ELECT
U702 0ISS524202B S524A40X21(SCT0) SAMSUNG ELECT
U801 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
U802 0TFFC80009A FAIRCHILD FDC6326L R/TP SOT-6
U803 0IPMGFA003B RC1117S-2.5 FAIRCHILD SOT-223
DATE: 2002. 10. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L101 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L811 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L823 6210TCE001Z HH-1M2012-600JT CERATEC R/TP C
L824 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
Q102 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q103 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q104 0TR162309CA KSC1623 TP SAMSUNG SOT23 NPN
Q108 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q201 0TR162309CA KSC1623 TP SAMSUNG SOT23 NPN
Q203 0TR162309CA KSC1623 TP SAMSUNG SOT23 NPN
Q701 0TR390609FA KST3906-MTF TP SAMSUNG SOT23
Q702 0TR390609FA KST3906-MTF TP SAMSUNG SOT23
R130 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R131 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R132 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R133 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R135 0RJ4703D677 470K OHM 1/10 W 5% 1608 R/TP
R140 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R142 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R145 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R150 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R151 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R153 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R160 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R161 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R170 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R171 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R172 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R201 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R203 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R204 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R205 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R206 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R207 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R208 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R209 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R210 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R211 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R214 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R215 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R216 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R217 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R218 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R219 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R221 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R223 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R224 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R225 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R226 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R227 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R228 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R234 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R235 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R236 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R237 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
- 27 -
DIODEs
ICs
COILs & COREs
RESISTORs
TRANSISTOR
