LG Flatron L1710B

DATE: 2002. 10. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R239 0RJ1001D477 1K OHM 1/10 W 1% 1608 R/TP
R242 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R243 0RJ3302D677 33K OHM 1/10 W 5% 1608 R/TP
R246 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R247 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R249 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R250 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R252 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R255 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R256 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R257 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R258 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R259 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R260 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R262 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R263 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R270 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R272 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R273 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R274 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R275 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R276 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R277 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R282 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R283 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R289 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R290 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R291 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R401 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R402 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R404 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R405 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R407 0RH0000D622 0 1/10W P-TYPE TAPPING
R408 0RH0000D622 0 1/10W P-TYPE TAPPING
R409 0RH0000D622 0 1/10W P-TYPE TAPPING
R702 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R703 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R704 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R705 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R706 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R711 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R712 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R713 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R714 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R715 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R716 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R718 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R719 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R726 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R727 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R729 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R732 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R733 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R734 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R740 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R741 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R742 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R743 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R744 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R745 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R746 0RH0000D622 0 1/10W P-TYPE TAPPING
R747 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
DATE: 2002. 10. 17.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R748 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R752 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R753 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R760 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R761 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R765 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R766 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R767 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R768 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R769 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R770 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R771 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R772 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R773 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R774 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R775 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R776 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R777 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R778 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R779 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R800 0RH0000D622 0 1/10W P-TYPE TAPPING
R801 0RH0000D622 0 1/10W P-TYPE TAPPING
R802 0RH0000D622 0 1/10W P-TYPE TAPPING
R809 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R810 0RH5600D622 560 1/10W 5 D.R/TP
R811 0RH0332D622 33 1/10W 5 D.R/TP
R812 0RH0332D622 33 1/10W 5 D.R/TP
R813 0RH0332D622 33 1/10W 5 D.R/TP
R814 0RH0332D622 33 1/10W 5 D.R/TP
R815 0RH0332D622 33 1/10W 5 D.R/TP
R816 0RH0332D622 33 1/10W 5 D.R/TP
R817 0RH0332D622 33 1/10W 5 D.R/TP
R818 0RH0332D622 33 1/10W 5 D.R/TP
R819 0RH0332D622 33 1/10W 5 D.R/TP
R820 0RH0332D622 33 1/10W 5 D.R/TP
R825 0RH0000D622 0 1/10W P-TYPE TAPPING
RA200 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA201 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA202 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA203 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA204 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA205 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA206 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA207 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA208 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA209 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA210 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA211 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
X201 6212AA2004B HC-49U TXC 20.0MHZ +/- 30 PPM
J1 6631T12002L 10P-11P H-B 60MM UL1061#28 LB8
LED1 0DLLT0208AA LITEON LTST-C155KGJSKT R/TP GR
SW1 140-058E SKHV10910B LGEC NON 12V 20A HO
SW2 140-058E SKHV10910B LGEC NON 12V 20A HO
SW3 140-058E SKHV10910B LGEC NON 12V 20A HO
SW4 140-058E SKHV10910B LGEC NON 12V 20A HO
SW5 140-058E SKHV10910B LGEC NON 12V 20A HO
- 28 -
OTHERs
CONTROL BOARD
