10
DISASSEMBLY-Stand
#1
Pull the Base 2 ea Latches to inside until losing elasticity.
#2
Consequently, pull the stand body directly.
#3
Separate Stand Body & Stand Base.
#4
Fix Stand Base & Stand Body.
#5
Remove the three screws.
#6
Separate the hinge and stand.
