16
1) Turn off the power switch at the front side of the display.
2) Wait for about 5 seconds and press MENU, POWER switch with 1 second interval.
3) The SVC OSD menu contains additional menus that the User OSD menu as described below.
a) CLEAR ETI: To initialize using time.
b) Auto Color: W/B balance and automatically sets the gain and offset value.
c) AGING: Select Aging mode (on/off).
d) PANEL: used panel type
e) NVRAM INIT: EEPROM initialize. (24C08)
f) R/G/B-9300K: Allows you to set the R/G/B-9300K value manually.
g) R/G/B-6500K: Allows you to set the R/G/B-6500K value manually.
h) R/G/B-Offset: Allows you to set the R/G/B-Offset value manually. (Analog Only)
i) R/G/B-Gain: Allows you to set the R/G/B-Gain value manually. (Analog Only)
Figure 1. Cable Connection for Micom uploading
SERVICE MODE
Connect to
the monitor
Connect to
the PC
To Next Page
