LG Flatron L1918S

39
VGA_CON
R437 470Ω 1/10W
C440 0. 1uF 16V
D409
ZMM5V6
C444
0.1uF 16V
CN405
DB15
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
1716
GREEN-
SCL_VGA
C434 0.047uF50V
R448
2.2KΩ 1/10W
BLUE-
RED+
R487 47Ω 1/10W
+5V
C436 0.047uF50V
C439 0.1uF 16V
DDCA_SCL4
D403
BAV99
3
1 2
R446 1KΩ 1/10W
R445 100Ω 1/10W
R434 56Ω 1/10W
FB409 120 OHM
R488 47Ω 1/10W
SOG 4
D411
ZMM5V6
HSYNC 4
DET_VGA 4
R455
1KΩ 1/10W
GNDB 4
C448
NC
R453 100Ω 1/10W
R452
10KΩ 1/10W
D405
BAV99
3
1 2
R450
4.7KΩ 1/10W
PC5V 2
D408
ZMM5V6
+5V 2,4
C438 0.047uF50V
RIN 4
VSY NC 4
PC5V
R441 100Ω 1/10W
R436 56Ω 1/10W
PC5V R438
75 OHM +-1% 1/10W
U404
M24C 02-R MN 6TP
1
2
3
45
6
7
8
A0
A1
A2
VSSSDA
SCL
WP
VCC
BIN 4
DDCA_SDA4
R444
10KΩ 1/ 10W
D404
BAV99
3
1 2
D407
BAV70
3
1 2
+5V
RED-
C447
NC
R439
75 OHM +-1% 1/10W
C433 0.047uF50VFB411 30 OHM1 2
R454 100Ω 1/10W
R447 1KΩ 1/10W
R449
2.2KΩ 1/10W
GIN 4
VCC3.3
FB410 30 OHM1 2
GREEN+
D412
ZMM5V6
VSI
FB412 30 OHM1 2
R443 100Ω 1/10W
GNDG 4
C441 0.1uF 16V
C443
22pF50V
C442
22pF50V
DDC_WP 4
PC5V
R435 56Ω 1/10W
BLUE+
D410
ZMM5V6
HSI
R440
75 OHM +-1% 1/10W
C432 0.047uF50V
SDA_VGA
R442 100Ω 1/10W
C435 1000pF/50V
R451
4.7KΩ 1/10W
D413
ZMM5V6
C437 0.047uF50V
D406
ZMM5V6
1 2
GNDR 4
