Name and Function of the Parts
•
Make sure to check the sound card connection terminal in the PC before connecting to the monitor.
If the PC sound card supports both Speaker Out and Line Out, change it to Line Out by setting the jumper or
the PC application. (For more details, refer to the sound card user’s manual.)
- Speaker Out : The terminal connected to the speaker that is not equipped with an amplifier.
- *Line Out : The terminal connected to the speaker equipped with an amplifier.
If Audio Out in the PC sound card has only Speaker Out, reduce the PC volume. This monitor is integrated
with an amplifier.
AV Input Terminal
Connecting the sound card output terminal
AV(CVBS) Input Terminal(Audio)
AV(CVBS) Input Terminal(Video)
S-Video Input Terminal
Headphone/Earphone Connection
Terminal
