Feature Highlight
23
Notes on Water Resistant Properties
This product is water and dust resistant in compliance with the Ingress
Protection rating IP68.
Your product has undergone testing in a controlled environment and is
proven to be water and dust resistant in certain circumstances (meets the
requirements of classification IP68 as described by the international
standard IEC 60529 - Degrees of Protection provided by Enclosures [IP
Code]; test conditions: 15-35 °C/59-95 °F, 86-106 kPa, 1.5 meters, for 30
minutes).
Do not expose the device in conditions that are different from the test
conditions. Results may vary in actual use.
WARNING
Despite a rating of IP68, your device is not impervious to conditions not
tested in LG’s controlled environment. Please note that any damages that
occur due to such causes changes the color of the LDI (Liquid Damage
Indicator). If the color of LDI located inside the product changes, the
product may be considered ineligible for any free-of-charge repair services
provided under the product’s limited warranty.
Avoid excessive dust or moisture as it may cause damages to the LDI or
other internally sealed components and therefore may render your product
ineligible for repair services provided under the product’s limited warranty.
Do not use the product in the following environments.
Do not immerse the product in any liquid chemicals (soap, etc.).
Do not immerse the product in salt water, including seawater.
Do not immerse the product in a hot spring.
Do not swim with this product.

Table of Contents

Other manuals for LG G7 ThinQ

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG G7 ThinQ and is the answer not in the manual?

LG G7 ThinQ Specifications

General IconGeneral
Screen shapeFlat
Pixel density564 ppi
Second displayNo
Display diagonal6.1 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness1000 cd/m²
Display resolution3120 x 1440 pixels
Native aspect ratio19.5:9
Orientation sensor-
Audio formats supportedAAC, AC3, AIFF, AMR, AWB, FLAC, MKA, MP2, MP3, OGG, WAV, WMA
Video formats supportedMP4
Processor cores8
Processor familyQualcomm Snapdragon
Processor frequency2.8 GHz
Graphics cardAdreno 630
PlatformAndroid
Virtual assistantGoogle Assistant
Google applicationsGmail, Google Chrome
App distribution platformGoogle Play
Operating system installedAndroid 8.0
RAM typeLPPDDR4X
RAM capacity4 GB
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size2000 GB
Internal storage capacity64 GB
Flash typeLED
White balanceAuto, Manual
Rear camera typeDual camera
Front camera typeSingle camera
Maximum frame rate120 fps
Video recording modes720p, 1080p, 2160p
Rear camera aperture number1.6
Resolution at capture speed1280x720@120fps, 1920x1080@60fps
Video capture resolution (max)3840 x 2160 pixels
Rear camera resolution (numeric)16 MP
Front camera resolution (numeric)8 MP
Second rear camera aperture number1.9
Talk time (3G)15.5 h
Battery capacity3000 mAh
Standby time (3G)100 h
4G standardLTE
2G standardsGSM
3G standardsHSDPA, HSUPA, UMTS
SIM card typeNanoSIM
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
3G bands supported850, 900, 1900, 2100 MHz
4G bands supported800, 1800, 2600 MHz
Bluetooth profilesA2DP, AVRCP, GATT, HFP, HID, HSP, MAP, OPP, PAN, PBAP, SAP
SIM card capabilitySingle SIM
2G bands (primary SIM)850, 900, 1800, 1900 MHz
Mobile network generation4G
Subscription typeNo subscription
USB version2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-C
HDMI ports quantity0
Headphone connectivity3.5 mm
Text prediction system typeT9
Multimedia Messaging Service (MMS)Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Body SAR (EU)1.466 W/kg
Head SAR (EU)0.244 W/kg
Color nameMoroccan Blue
Form factorBar
Product colorBlue
Protection featuresDust resistant, Water resistant
International Protection (IP) codeIP68
Weight and Dimensions IconWeight and Dimensions
Depth7.9 mm
Width71.9 mm
Height153.2 mm
Weight162 g
