1
2
1
3
4
• To Remove the shelf from refrigerator, at first – lift up it (1),
and then – pull it out side (2). In case of wrong removing
of the shelf, the damages of inner surfaces of refrigerator
possible.
• To install shelf into refrigerator follow similar: lift up
front side of the shelf at the angle (3) and then insert
it inside (4). In case of wrong installing of the shelf,
the damages of inner surfaces of refrigerator possible.
Remove/Install
shelf
Lamp
Replacement
1. Unplug the power cord from the outlet.
2. Remove fridge shelves.
3. To remove the lamp cover, insert type
driver in the underside of the lamp
cover and pull it out forwards.
4. Turn the lamp counterclockwise.
5. Assemble in reverse order of
disassembly. Replacement lamp must
be the same specification as original.
6. MAXIMUM rated input of lamp should
not to exceed 20 W.
Warning
To Next Page
