1. Operation Principle
1-1. Operation Principle of Icemaker
1. Turning the Icemaker switch off (O) stops the ice making function.
2. Setting the Icemaker switch to OFF and then turning it back on will reset the icemaker control.
¥ Adjusts EJECTOR to
Start Position
with power on.
Power On
Start Position
Icemaking
Mode
Harvest
Mode
Park Position
Fill
Test Mode
¥ Waits until water becomes ice after starting the
icemaking operation.
¥ Runs MOTOR to drop ice from the tray into the ICE BIN.
(During harvest mode, check if the ice bin is full)
¥ Performs
Ice Making Mode
after supplying water by operating
the SOLENOID in ICE VALVE.
¥ To operate LINE and SERVICE, press and hold the
Water
amount selection button
for 3 seconds.
The icemaker will run through 3 stages:
Harvest Fill Icemaking
.
¥ With the detect lever, checks if the ICE BIN is full.
