HOW T
O DISASSEMBLE AND ASSEMBLE
- 88
-
7) Dispenser Related Parts
18
21
20
19
7
8
14
17
15
9
10
16
1
2
22
13
12
3
4
1
FRAME ASSEMBL
Y
, DISPLA
Y
2
COVER, DISPENSER
3
DECO, FRAME DISPLA
Y
4
PWB(PCB) ASSEMBL
Y
, DISPLA
Y
7
FUNNEL ASSEMBL
Y
8
MICRO SWITCH
9
FRAME, FUNNEL
10
LEVER(SWITCH)
1
1
FUNNEL
12
BUTTON LEVER
13
HOLLDER BUTTON
14
SOLENOID ASSEMBL
Y
15
SPRING
16
LEVER HOLDER
17
CAP ASSEMBL
Y
, DUCT
18
CAP
, DUCT
19
DISPENSER LEVER
20
FOAM, NEW
21
RUBBER, CAP
22
DECO, DRAIN
NOTE : Not every model includes every option
